Factory Direct Industrial Air Cooler Double Side Blow Unit Cooler Rooftop Evaporator For Vegetable Cold Storage
Product Details:
| Place of Origin: | China |
| Brand Name: | Xinda |
| Certification: | ISO/CE |
| Model Number: | CDD-100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 300-390 per unit |
| Packaging Details: | Wooden case packing |
| Delivery Time: | 15-30 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 3000 units per month |
|
Detail Information |
|||
| Suitable Room Temperature:: | CDL: -5~+5, CDD: -15~ -20, CDJ: Below -25 Degree | Standard Package:: | Wooden Case And Pallet |
|---|---|---|---|
| Type: | Evaporative Air Cooler | Power Supply:: | 380V/50Hz/3phase Or 220V/50Hz/1p |
| HS Code:: | 84189910 | Production Capacity:: | 3000 Pieces / Month |
| Origin:: | China/Shengzhou | Shell Material: | Plastic Sprayed Metal Plate /Stainless Steel |
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops | Fin Spacing: | 9mm |
| Installation : | Ceiling Mount | ||
Product Description
Product Description
Refrigeration capacity of this series covers from4.4KW to39.4KW, fitting with different refrigerant such as R134a·R404A·R507A·R407C·R22.
Characteristics
1. Reasonable structure, uniform frosting and high heat exchange efficiency
2. The shell is made of high-quality steel plate, with plastic-sprayed surface, corrosion resistance and beautiful appearance;
3. Special fan motor is selected, with low noise, large air volume and stable operation;
4. The stainless steel U-shaped tubular electric heating tube with strong insulation is used. The electric heating tube is put into the fin, evenly distributed, and defrosting time is short, and the effect is good;
5. The shell material can be made of embossed aluminum plate and stainless steel according to customer requirements;
6. The air cooler shall be tested under the pressure of 2.8MPa to ensure the stability of the product in use.
2. The shell is made of high-quality steel plate, with plastic-sprayed surface, corrosion resistance and beautiful appearance;
3. Special fan motor is selected, with low noise, large air volume and stable operation;
4. The stainless steel U-shaped tubular electric heating tube with strong insulation is used. The electric heating tube is put into the fin, evenly distributed, and defrosting time is short, and the effect is good;
5. The shell material can be made of embossed aluminum plate and stainless steel according to customer requirements;
6. The air cooler shall be tested under the pressure of 2.8MPa to ensure the stability of the product in use.
Sphere of Application
High temperature type:
(cold room temperature 12~- 2ºC)fin space:4.5mm;
Medium temperature type:
(cold room temperature-2 ~- 10ºC) fin space:6.0mm;
Low temperature type:
(cold room temperature - 10~-31ºC)fn space:9.0mm;
Made for customers
Sphe
re of application
Technical Parameter
Product Photos
FAQ
Q1.Are you a factory or a trading company
A1.We are a factory.
Q2.Which refrigerant do you need?
A2.R22,R404a and accept customers' request.
Q3. Which condenser do you prefer?
A3.Air cooled /water cooled and evaporative cooled tower.
Q3. What is the ambient temperature and water inlet temperature?
A3.Refrigerating capacity and power input based on ambient temperature 32ºC, condensing temperature 45ºC.
(PS: If Rack run at higher/lower evaporating temperature or ambient temperature, please contact with our company)
Q5. What is the power?
A5.Rack main power supply is 3 phase,380V/50HZ, control power supply is 1 Phase, 220V/50HZ.
(PS:We can make the power according to your request)
Q6. What is your warranty?
A6.We can assure you one year against manufacturing defect.
